HWP20000Y2P – 20,000lb Commercial Hydraulic Winch (Manual + Air Clutch)

The HWP20000Y2P is a heavy-duty hydraulic winch built for demanding commercial, industrial and recovery applications. Delivering a massive 20,000lb (9,072kg) of pulling power and equipped with 48 metres of 14mm steel cable, this unit is designed for extreme-duty recoveries and large equipment handling. The single-speed motor offers strong, consistent pulling performance, while the dual-mode clutch allows the operator to engage the clutch manually or via air for quicker, easier activation. The efficient two-stage planetary gearbox provides smooth torque transfer, and the automatic wet-type hydraulic disc brake ensures secure load holding at all times. With full IP67 ingress protection, this winch is engineered to operate reliably in mud, water, dust and harsh weather conditions. It is suited for tow trucks, recovery trucks, expedition vehicles such as Unimog and Iveco Daily, marine applications, forestry machinery, log splitters and industrial hydraulic systems. Optional accessories include wired or wireless remotes, directional control valves (12V or 24V), and valve blocks for complete hydraulic control integration.

Key Features

• 20,000lb (9,072kg) hydraulic pulling power
• Single-speed motor with strong, steady load performance
• Dual-mode clutch (manual or air activation)
• Massive 48m drum capacity with 14mm steel cable
• Automatic wet-type hydraulic disc brake
• Two-stage planetary gearbox for efficient power transfer
• Rated IP67 for harsh environment operation
• Heavy-duty mounting options with multiple bolt patterns

Technical Specifications

Rated Line Pull: 20,000lb (9,072kg)
Motor Displacement: 100ml/r
Oil Flow Requirement: 25–75 L/min
Pressure Requirement: 17.5MPa
Gear Train: Full steel, 2-stage planetary
Gear Ratio: 39:1
Clutch: Manual + air
Brake: Automatic hydraulic disc
Cable: 14mm × 48m steel cable
Drum Size: 138mm × 316mm
Mounting Bolt Patterns: 431mm × 64mm and 431mm × 192mm (8 × M14)
Overall Dimensions: 835mm × 390mm × 320mm
Finish: Red powder coat
Warranty: 18-month commercial warranty
SKU: HWP20000Y2P

Performance

0kg – 2.5MPa, 15 L/min, 1.8 m/min
1,814kg – 4.2MPa, 30 L/min, 3.6 m/min
3,629kg – 8.5MPa, 50 L/min, 6.0 m/min
6,804kg – 14.0MPa, 60 L/min, 7.2 m/min
9,072kg – 17.5MPa, 75 L/min, 9.0 m/min
Rated Line Pull by Layer: 1st – 20,000lb, 2nd – 16,889lb, 3rd – 14,615lb, 4th – 12,881lb. Total rope on drum: 48m.

Optional Accessories

Wired remote, wireless remote, directional control valve (12V or 24V), valve block.

Ideal Applications

Heavy tow trucks, recovery rigs, expedition trucks, marine vessels, forestry equipment, industrial machinery, large hydraulic systems and high-demand commercial environments.

Why Choose This Winch

Built for extreme-duty workloads, the HWP20000Y2P provides exceptional pulling strength, dual clutch flexibility, long service life and dependable operation in the harshest environments.
