JIC x UNO Male/Male Straight Adaptors connects JIC Female to UNO ports on valves, pumps & cylinders
SKU JIM-UNM-0709
AU$3.30
On Sale
was AU$3.60 Save 8%
JIC Male x UNO Male ( eg JIM-UNM-0707)
Please choose
In stock
1
Save this product for later
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
JIC x UNO Male/Male Straight Adaptors connects JIC Female to UNO ports on valves, pumps & cylinders
Product Details
Brand: ENGMATTEC
Weight: 0.08 kg
JIC x UNO male/male Adapters are used to enable High Pressure Hydraulic Fluid Connections between hydraulic components.
For example when connecting a Hydraulic Hose or pipe with JIC Female fitting to: Motors, Pumps, Valves, and cylinders with female threaded UNO ports.
Or to put it another way, JIC to UNO male/male adaptors are used: when you want to connect a high pressure hydraulic pipe or hose to a valve, motor, pump or cylinder that has female UNO ports and your hoses or pipes have JIC Female Threads.
Please be aware that all thread sizes are not straight forward, ie you must measure & compare.
Please see chart below for measurements.
If you need a size not listed, please call or email & we'll add it or even better yet.
| JIC/UNO THREAD ID CHART | ||||||
| Male Thread OD & Pitch | DASH SIZE | Male Thread OD | Female Thread OD | TUBE SIZE | ||
| inch – TPI | mm | inch | mm | inch | inch | |
| 7/16 – 20 UNF | -07 | 11,1 | 0.44 | 9,9 | 0.39 | 1/4 |
| 9/16 – 18 UNF | -09 | 14,3 | 0.56 | 13,0 | 0.51 | 3/8 |
| 3/4 – 16 UNF | -12 | 19,1 | 0.75 | 17,5 | 0.69 | 1/2 |
| 7/8 – 14 UNF | -14 | 22,2 | 0.88 | 20,3 | 0.80 | 5/8 |
| 1.1/16 – 12 UNF | -17 | 27,0 | 1.06 | 24,9 | 0.98 | 3/4 |
| 1.3/16 – 12 UNF | -19 | 30,2 | 1.19 | 28,2 | 1.11 | 7/8 |
| 1.5/16 – 12 UNF | -21 | 33,3 | 1.31 | 31,2 | 1.23 | 1 |
| 1.5/8 – 12 UNF | -26 | 41,3 | 1.63 | 39,1 | 1.54 | 1.1/4 |
| 1.7/8 – 12 UNF | -30 | 47,6 | 1.88 | 45,5 | 1.79 | 1.1/2 |
| 2.1/2 – 12 UNF | -40 | 63,5 | 2.50 | 61,5 | 2.42 | 2 |
Email: click here to email us
Phone: 07 5563 1982
Hours: 8 am to 5 pm Monday - Friday, AEST excluding public holidays
If you have any questions please don’t hesitate to contact us
Best regards,
Hydraulic.Online
Improper Selection, Installation, Implementation, And/Or Operation By Anyone Other Than Persons With Appropriate Technical And Mechanical Training Can Result In Damage To Equipment Or Property, Serious Personal Injury, Or Death. Proper Precautions And Safety Procedures Should Be Implemented Prior To The Installation And Operation Of Equipment.
