Hydraulic Flow Control Valve 3-4inch BSP Ports 3-Spool 80 LtMin TILT TRAY

Hydraulic Flow Control Valve 3/4" BSP Ports 3-Spool 80 Lt/Min TILT TRAY

Name: Hydraulic Flow Control Valve 3/4" BSP Ports 3-Spool
Brand: Youli
SKU: MB5-3 pt
Price: 989.1 AUD
Availability: InStock

Store/Valves for Controlling and Directing Oil Flow and Pressure/Monoblock Directional Control Valves

SKU MB5-3 pt

AU$989.10

🔥 EOFY SALE!

Power Beyond Plug

Power Beyond (+AU$33.00)

No Power beyond

In stock

Quantity:

Save this product for later

Customer reviews

Reviews only from verified customers

No reviews yet. You can buy this product and be the first to leave a review.

Hydraulic Flow Control Valve 3/4" BSP Ports 3-Spool 80 Lt/Min TILT TRAY

Store/Valves for Controlling and Directing Oil Flow and Pressure/Monoblock Directional Control Valves

Product Details

Brand: Youli

Weight: 14.00 kg

This is a brand new high quality Youli 3 spool 80Lpm valve, it is designed for Tilt Tray Trucks, Cranes. Skip Bin Trucks, Front end Loaders, Backhoes or any application where you need to control 3 individual functions or cylinders.

These valves are regularly used in hydraulic circuits to divert the flow of high pressure oil and are typically used to control the speed and movement of hydraulic cylinders or motors. These are proven quality valves. This item weighs 13Kg

Specifications

Construction = Monoblock
Material of Construction = Steel
No of Spools = 3
Material of Construction = Case Hardened Steel
O-rings made of NBR (Buna-N®)
Max Flow Rate = 80 liters/min (20 Gallons per Minute)
Max Working Pressure = 315 Bar (4750 PSI)
Spool Type = Cylinder. Motor Spools also available
Spool Movement = Lever action, No Spring Return to Center.
Detent Kits $60
Power Beyond Plug $35
Built in Relief Valve = Adjustable (factory set at 2500 PSI)
Dimensions. Please refer to photos, Model MB5/3S
Ports Sizes
Pressure Port 3/4" BSPP
Cylinder Ports 1/2" BSPP
Tank Port 1" BSPP
Operating temperature range: -20 °C to + 80°C
Weight 13 KG

Please send us a message for different spool configurations, spool numbers and costings.

This a High Quality Valve and has many outstanding features, including.

built in adjustable relief valve
high performance,
high efficiency,
small volume,
mass flow,
leak resistance.

In additional to compact size, these control valves have fixed and large pull rods to control direction,

Please note*

These 80 LPM valves require a separate "Power Beyond" sleeve to operate a valve downstream.

Detent is when a you push/pull a lever, it stays forward/back at that position until you move it back to the centre.

Installation ; As per photos, there are a choice of two pressure ports "P" (only use one), two "T" Tank return ports and also there is a "C" port. This "C" port is for the: Power Beyond function. This allows another valve to run pressure from this C port downstream if necessary. (must be a lower volume though). A & B ports run to your cylinder or other functions.
