Youli MB3 Monoblock Valve – 2 Spool, 45 L/min, 3/8" BSPP

Name: 2 Spool Hydraulic Monoblock Valve 45 LPM | Youli MB3
Brand: Youli
SKU: MB3-2SP-SERIES
Price: 441.14 AUD
Availability: InStock

Store/Valves for Controlling and Directing Oil Flow and Pressure/Monoblock Directional Control Valves/45 to 60 Lt/Min Monoblock Flow Control Valves

SKU MB3/2S3/18L/G4-3-4-M3

AU$441.14

Configuration

Please choose

In stock

Quantity:

Save this product for later

Customer reviews

Reviews only from verified customers

No reviews yet. You can buy this product and be the first to leave a review.

Share this product with your friends

Share Share Pin it

Youli MB3 Monoblock Valve – 2 Spool, 45 L/min, 3/8" BSPP

Store/Valves for Controlling and Directing Oil Flow and Pressure/Monoblock Directional Control Valves/45 to 60 Lt/Min Monoblock Flow Control Valves

Product Details

Brand: Youli

Weight: 4.90 kg

Youli MB3 Monoblock Directional Control Valve - 2 Spool, 45 L/min

Two independent functions - lift and tilt on a loader, or any two rams/motors. 45 L/min, 250 bar. The float config puts a detented float position on the second lever.

Pick your configuration from the dropdown - each choice is a factory-built valve with its own part number that flows straight through to our warehouse. All prices include GST.

Cylinder spool (closed centre, standard) - ports closed in neutral, holds the load. For rams.
Motor spool (open centre) - ports open to tank in neutral so a motor can coast.
Single-acting spool - one work port for single-acting rams and tippers.
FLOAT spool (5PYL) - detented 4th position opens ports to tank so a bucket or deck follows the ground.

Sizes & Part Numbers - every configuration

Configuration	SKU	Best for	Price inc GST
Both levers Cylinder spools – STANDARD	MB3/2S3/18L/G4-3-4-M3	Two rams - holds loads	AU$441.14
Cylinder + FLOAT spool	MB3/2S3/5PYL/G4-3-4-M3	Ram + ground-following loader	AU$741.31

Need a different spool mix, detents, micro-switches, pneumatic or 12/24V solenoid control? Every combination can be factory-coded - call us and we will build the part number with you.

Specifications

Flow: 45 L/min | Pressure: 250 bar nominal | Ports: 3/8" BSPP
Adjustable inlet relief valve (63-200 bar standard, 40-80 & 160-315 bar options)
Spring-return 3-position levers | Made in Taiwan (Youli)

Technicians Advice

Cylinder (closed centre) spools hold a load in neutral; motor (open centre) spools let a spinning motor coast - do not run a motor on a cylinder spool. The inlet relief ships on a standard setting: set it to YOUR system pressure with a gauge on P at first start. Detent, micro-switch, pneumatic and solenoid controls all retrofit per spool - call us with the function list and we will code it. Power beyond needs the MB3 plug (below) and a dedicated tank return line.

Official Datasheets

📄 Youli MB3 Factory Spec Sheet

Complete Your Setup

⭐ Power Beyond Plugs (MB3)⚙ MB3 1-Spool ⚙ MB3 3-Spool ⚙ MB3 Joystick Valves

Buy in bulk and save: 5+ units −5%, 10+ −10%, 25+ −12.5%, 50+ −15% — applied automatically in the cart.

Not sure? Call 1300 146 737 or email sales@mhfgc.com.au - we will code the valve for you.
