122 M reel of Gates Pro Series 6 CR2 3/8"inch Inside Diameter, Smooth Cover 2 wire Hydraulic Hose, with MSHA certification

122 M rell of Premium quality GATES Pro Series 3/8"inch ID 330 bar (4,800 PSI) working pressure
Flame Resistant high temp 100°C Two Wire Hydraulic Hose.

Gates 6 CR2 two-wire hydraulic hoses are fully compatible, interchangeable, with most other hydraulic hose brands and types. Compatible with our swage on hosetails or re usable hosetails

Specifications and Construction

Pressure tested to 130% of full working pressure for at least 200,000 cycles.

Applications:
High-pressure service with petroleum base hydraulic fluids, water,
Air, water-glycol, hot oil, grease, lubricants, crude, and fuel oils.
Please note: For air applications above 100psi, the cover should be pin pricked

Hose Specifications

• Pressure Ranges
• Working Pressure: 330 Bar (4,800 PSI)
• Burst Pressure: 19,200 PSI (Minimum)
• Range of Temperature -40⁰ C to + 100⁰ C
• Minimum Bend Radius 130 mm
• Weight 0.57 KG / M

Click Here to see the full Range of Gates CR2 Pro Series two Wire Hydraulic Hoses

• Agriculture
• Construction
• Mining
• Manufacturing
• Return Lines
• Low Flex Accessory Lines
• Auxiliary Lines
• Drain Lines

Please contact us for a more competitive shipping rate.
We are able to send through freight depot to depot.
If you are after something in particular, please send us a message.
