SAE 100R7 1/4" NC ThermoPlastic Non Conductive Hydraulic Hose
Made from a thermoplastic Elastomer inner liner, with 1 braid synthetic fibre reinforcement, and an orange non-conductive polyurethane Outer Cover.

Specifications

Working pressure = 190 bar (2,800 psi)
Minimum Bend radius =100 mm
Range of Temperature- -40˚C to +100˚C

Suitable for hydraulic applications with increased resistance to abrasion especially in Corrosive, Wet or Marine Conditions.
Also suitable for Irrigation and Dust Suppression Systems and Cherry pickers.

For use with petroleum, synthetic or water based fluids in Hydraulic systems.
Suitable for agricultural machinery, earthmoving, articulating and telescopic booms, elevated work platforms and material handling equipment.

Must be used in applications requiring high electrical insulation or non-conductivity eg EWPs (Elevated Work Platforms).
