Hydraulic Hose Burst Sleeve MSHA Nylon 18–110mm ID | 50 Metre Rolls
Product Details
Brand: Hydraulic.Online
Weight: 1.31 kg
Hydraulic Hose Burst Sleeve – MSHA Nylon Safety Sleeve (50 Metre Rolls)
Heavy-duty woven nylon burst sleeve that protects operators from high-pressure oil-injection injury if a hydraulic hose bursts — and shields the hose itself from abrasion and UV. MSHA accepted, the standard fit-out on mining, civil and forestry machinery, and increasingly required on construction sites.
Fits like a sock: slide it over the hose before the second fitting is crimped, or specify it on new assemblies. If sliding a sleeve on is not an option, see our Velcro-closure burst sleeve range. Sold in full 50 metre rolls only — 12 sizes from 18mm to 110mm inside diameter.
- Protects operators from oil-injection and hose-whip injuries
- MSHA accepted woven nylon — abrasion and UV resistant
- Sizing = sleeve inside diameter; pick the next size up from your hose OD
Size & Roll Guide
| Sleeve ID | Flat Width | Suits Hose OD (max) | Metres per Roll | Our SKU | Roll Weight |
|---|---|---|---|---|---|
| 18 mm | 32 mm | up to 18 mm | 50 m | PSB-18-50 | 1.31 kg |
| 23 mm | 44 mm | up to 23 mm | 50 m | PSB-23-50 | 1.8 kg |
| 25 mm | 46 mm | up to 25 mm | 50 m | PSB-25-50 | 1.89 kg |
| 29 mm | 50 mm | up to 29 mm | 50 m | PSB-29-50 | 2.05 kg |
| 36 mm | 61 mm | up to 36 mm | 50 m | PSB-36-50 | 2.5 kg |
| 40 mm | 67 mm | up to 40 mm | 50 m | PSB-40-50 | 2.75 kg |
| 45 mm | 75 mm | up to 45 mm | 50 m | PSB-45-50 | 3.07 kg |
| 56 mm | 92 mm | up to 56 mm | 50 m | PSB-56-50 | 3.77 kg |
| 63 mm | 103 mm | up to 63 mm | 50 m | PSB-63-50 | 4.22 kg |
| 71 mm | 116 mm | up to 71 mm | 50 m | PSB-71-50 | 4.75 kg |
| 93 mm | 150 mm | up to 93 mm | 50 m | PSB-93-50 | 6.15 kg |
| 110 mm | 177 mm | up to 110 mm | 50 m | PSB-110-50 | 7.25 kg |
Which Size Suits My Hydraulic Hose?
Sleeve sizing is by inside diameter: measure your hose OD and pick the next sleeve size up. Typical hose OD → recommended sleeve:
| Hose Type | Dash / OD (mm) → Sleeve |
|---|---|
| SAE 100R1 / 1SN | -4 13.2→18mm | -6 17.2→18mm | -8 20.4→23mm | -10 23.5→25mm | -12 27.8→29mm | -16 35.6→36mm | -20 43.5→45mm | -24 50.6→56mm | -32 64.1→71mm |
| SAE 100R2 / 2SN | -4 15.0→18mm | -6 19.0→23mm | -8 22.1→23mm | -10 25.4→29mm | -12 29.5→36mm | -16 38.1→40mm | -20 47.4→56mm | -24 54.6→56mm | -32 67.3→71mm |
| SAE 100R12 (4-spiral) | -6 19.5→23mm | -8 22.3→23mm | -10 26.4→29mm | -12 30.7→36mm | -16 37.8→40mm | -20 45.5→56mm |
| SAE 100R15 (6-spiral) | -6 20.0→23mm | -8 23.0→25mm | -10 26.5→29mm | -12 32.2→36mm | -16 39.2→40mm | -20 49.4→56mm | -24 57.3→63mm | -32 71.9→93mm |
| SAE 100R7 (thermoplastic) | -3 10.5→18mm | -4 12.7→18mm | -6 16.3→18mm | -8 20.1→23mm | -12 26.4→29mm | -16 33.3→36mm |
Hose outside diameters vary between brands, series and cover types — always measure your hose OD before ordering. Multi-hose bundles: add the ODs and allow clearance.
