Galtech Q45 Monoblock Valve – Solenoid Operated 12/24V DC, 60 L/min, 1/2" BSPP
Store/Valves for Controlling and Directing Oil Flow and Pressure/Monoblock Directional Control Valves/45 to 60 Lt/Min Monoblock Flow Control Valves
Product Details
Brand: Galtech
Weight: 7.40 kg
Galtech Q45 Monoblock Valve – Solenoid Operated 12/24V DC, 60 L/min, 1/2" BSPP
The same Italian-made Galtech Q45 monoblock valve, factory-fitted with genuine Galtech on/off solenoid operators so you can run it from a switch, relay or radio remote instead of standing at the levers. Every powered bank keeps a manual override handle – if you ever lose power, you never lose control.
Ways to buy:
- Off the shelf: pick 1, 2 or 3 spools and your coil voltage below. Every bank is solenoid operated with manual override.
- Mixed banks (some electric, some manual), 4+ spools, or electric-over-air – call us, we build these to order.
Pick your kit
| Spools | Voltage | Kit SKU | Price (inc GST) |
|---|---|---|---|
| 1 spool | 12V DC | KIT-Q45-1S-ES12 | $1,032.83 |
| 1 spool | 24V DC | KIT-Q45-1S-ES24 | $1,032.83 |
| 2 spool | 12V DC | KIT-Q45-2S-ES12 | $1,750.50 |
| 2 spool | 24V DC | KIT-Q45-2S-ES24 | $1,750.50 |
| 3 spool | 12V DC | KIT-Q45-3S-ES12 | $2,552.43 |
| 3 spool | 24V DC | KIT-Q45-3S-ES24 | $2,552.43 |
What is in each kit
| Component | Qty (per kit) |
|---|---|
| Galtech Q45 monoblock valve (Q45M/1, /2 or /3) – D/A cylinder spools, spring return | 1 |
| Galtech on/off solenoid kit, your chosen voltage (02571 103/71 = 12V, 02571 103/72 = 24V) | 1 per bank |
| Manual override handle (06.029.28945.99/N) | 1 per bank |
Specifications
| Parameter | Value |
|---|---|
| Brand / Origin | Galtech – Made in Italy |
| Max flow / pressure | 60 L/min – 350 bar (1–2 spool), 320 bar (3 spool) |
| Ports | 1/2" BSPP |
| Solenoid type | On/off (bang-bang), DIN 43650-A plug connection |
| Coil voltage | 12V DC or 24V DC – select above |
| Manual override | Yes – lever on every powered bank |
| Duty | Continuous rated coils |
How to choose
- Voltage: match your machine battery – 12V for most utes, trucks and plant; 24V for larger trucks and industrial gear.
- Wiring: each bank needs two wires (A and B direction) plus common – the DIN plugs are included on the coils. See the wiring diagram in the photo gallery.
- Radio remote? Pair this valve with one of our wireless remote kits – call us and we will wire the receiver channels to match your bank count.
Technicians Advice
On/off solenoid valves like this are perfect for tippers, tailgates, winches, log splitters and any job where you flick a switch and the ram goes. They are not proportional – the oil is either flowing or it is not – so if you need feathering control for a crane or grab, talk to us about proportional options instead. Fuse each coil circuit at 5A, use marine-grade connectors anywhere near the weather, and if your run from the battery is over 5 metres, go up a wire gauge – low voltage at the coil is the number one cause of lazy solenoid valves we see in the workshop.
Official Datasheets
📄 Official Galtech Q45 Factory Datasheet (PDF) 📄 Galtech Q45 Series Spec Sheet (PDF)
