Diesel Hydraulic Power Pack — Yanmar L-Series | 8 or 14.2 Lt/min

Name: Diesel Hydraulic Power Pack | Yanmar L-Series | Australia
Brand: Yanmar / Mocen
SKU: L70NGEU- L100NGEU
Price: 6511.0 AUD
Availability: InStock

Store/Power Packs and Hydraulic Power Units 12 & 24 VDC, 240 & 415 VAC, Petrol or Diesel/Petrol & Diesel Power Packs

SKU L70N-GEU07010H278B

AU$6,511.00

On Sale

was ~~AU$10,962.00~~ Save 41%

Power, Flow and Oil Delivery Options

Please choose

Yanmar L70N or L100N diesel HPU — P+T or Double-Acting Cetop 3 | 8 or 14.2 LPM | 3,000 PSI | Recoil & Electric Start

In stock: 5 available

Quantity:

Save this product for later

Customer reviews

Reviews only from verified customers

No reviews yet. You can buy this product and be the first to leave a review.

Diesel Hydraulic Power Pack — Yanmar L-Series | 8 or 14.2 Lt/min

Store/Power Packs and Hydraulic Power Units 12 & 24 VDC, 240 & 415 VAC, Petrol or Diesel/Petrol & Diesel Power Packs

Product Details

Brand: Yanmar / Mocen

Weight: 51.00 kg

Diesel Reliability. Lower Running Costs.

All-Day Hydraulic Power — Anywhere.

When the job runs long and fuel costs matter, diesel wins. Our Yanmar L-Series diesel hydraulic power packs are built for extended duty cycles — farms, hire fleets, civil works, and remote industrial applications where petrol isn't the practical choice. Yanmar's proprietary direct injection technology delivers maximum power from minimum fuel, backed by one of the most trusted small diesel engine names in the world. Available in two engine sizes and two valve configurations — choose the combination that fits your application.

Why Yanmar L-Series?

⛽ Direct Injection

Yanmar's proprietary FIE (Fuel Injection Equipment) system — one of the world's smallest miniaturised direct injection systems — extracts maximum power from every drop of diesel. Lower fuel consumption per hour than equivalent petrol engines.

🔈 Low Vibration & Noise

Precision balancers reduce vibration and noise to a level that allows comfortable operation during long work hours — a significant advantage over budget diesel engines in extended-duty applications.

⚡ Easy Starting

Yanmar's auto-return decompressor and efficient combustion system make recoil starting straightforward — even in cold conditions. Electric start is also standard on both the L70N and L100N, so there's no hard pulling on the job site.

🌿 EPA Tier 2

Emissions compliant to EPA Tier 2 standards. Suitable for use in environmentally sensitive areas and applications where emissions compliance is a requirement of the contract or site specification.

Who Uses This Unit?

🚗 Farmers & Rural Operators

Diesel is the preferred fuel on most Australian farms — bulk storage, lower cost per litre, and longer run times between fills. Ideal for log splitters, post hole diggers, fence post drivers, workshop presses, and irrigation pumping across large properties.

🏭 Hire Fleets & Industrial

Hire companies favour diesel for its reliability, longer service intervals, and lower fuel cost per hour. Yanmar's commercial-grade construction means these units withstand the rough handling of hire fleet life and run all day without complaint.

👷 Contractors & Civil Works

Remote civil and infrastructure projects where diesel bulk supply is already on site. Extended run times without refuelling, lower operating costs over the life of the project, and no reliance on petrol logistics.

Step 1 — Choose Your Engine Size

Yanmar L70N — 6.1hp / 8 LPM

6.1hp max (5.5hp continuous) @ 3,000 RPM — Suits light to medium duty applications

The L70N delivers 8 LPM at 3,000 RPM — the right match for single-function hydraulic tools and equipment with moderate flow demand. Compact and lightweight (36kg recoil / 41kg electric start), it suits trailer mount, ute tray, or skid-frame installations where weight and space are a consideration.

Max output: 6.1hp / 4.5kW @ 3,000 RPM
Continuous rated: 5.5hp / 4.1kW @ 3,000 RPM
Flow rate: 8 LPM
Engine weight: 36kg (recoil) / 41kg (electric start)
Displacement: 320cc
Bore × stroke: 78 × 67mm

Best for: log splitters, post drivers, compactors, single-function tools.

Yanmar L100N — 8.8hp / 14.2 LPM

8.8hp max (7.7hp continuous) @ 3,000 RPM — Suits medium to heavy duty applications

The L100N steps up to 14.2 LPM — significantly higher flow for faster cylinder cycle times, larger bore cylinders, or multi-function valve stacks. At 48.5kg (recoil) or 53.5kg (electric start), it's still a portable unit but delivers performance closer to a mid-range power pack.

Max output: 8.8hp / 6.5kW @ 3,000 RPM
Continuous rated: 7.7hp / 5.7kW @ 3,000 RPM
Flow rate: 14.2 LPM
Engine weight: 48.5kg (recoil) / 53.5kg (electric start)
Displacement: 435cc
Bore × stroke: 86 × 75mm

Best for: rock breakers, larger bore cylinders, multi-function valve stacks, higher-demand applications.

Step 2 — Choose Your Valve Configuration

Option A — P&T Ports Only

Connect your own directional control valve

Pressure and tank ports only — no valve fitted. Connect your own lever-operated monoblock or sectional directional control valve. The lower-cost base configuration, ideal when you already have a valve or prefer manual lever control.

Best for:

Log splitters & tip trailers
Workshop presses
Applications with existing manual valve
Lowest cost base configuration

Part numbers:

L70N: L70N-GEU07010H278B

L100N: L100N-GEU07010H488B

📄 Kit Documentation

› L70N P&T Kit Drawing — available soon

› L100N P&T Kit Drawing — View / Download PDF

🔗 You'll Also Need

› Monoblock Directional Control Valves — lever-operated, suits P&T port connection

› JIC / UNO Adaptors — required to connect JIC hose ends to 9/16" UNO ports

Option B — Double Acting Cetop 3

Factory-fitted 12V DC solenoid valve included

Includes a factory-fitted Cetop 3 double-acting solenoid valve (closed centre, 12V DC). Controlled via pendant switch or push-button — no lever required. Ideal for remote or stand-clear operation, or where the operator needs both hands free.

Best for:

Post drivers & rock breakers
Compactors & tampers
Hydraulic tools requiring remote control
Any double-acting cylinder or hydraulic motor

Part numbers:

L70N: L70N-GEU07131H278B

L100N: L100N-GEU07131H488B

📄 Kit Documentation

› L70N D/A Kit Drawing — View / Download PDF

› L100N D/A Kit Drawing — View / Download PDF

🔗 You'll Also Need

› Remote Control Pendant D/A KCB22-03 — push-button 12V DC pendant switch for solenoid valve control

› JIC / UNO Adaptors — required to connect JIC hose ends to 9/16" UNO ports

Technical Specifications

Specification	L70N (6.1hp / 8 LPM)	L100N (8.8hp / 14.2 LPM)
Engine	Yanmar L70N5	Yanmar L100N5
Engine Type	4-stroke, single cylinder, air-cooled diesel, direct injection
Max Rated Output	6.1hp / 4.5kW @ 3,000 RPM	8.8hp / 6.5kW @ 3,000 RPM
Continuous Rated Output	5.5hp / 4.1kW @ 3,000 RPM	7.7hp / 5.7kW @ 3,000 RPM
Displacement	320cc	435cc
Bore × Stroke	78 × 67mm	86 × 75mm
Start Type	Recoil (pull start) + Electric start — both standard
Fuel	Diesel
Fuel Tank Capacity	3.3 litres	5.4 litres
Gear Pump Displacement	2.7cc	4.8cc
Flow Rate	8 LPM @ 3,000 RPM	14.2 LPM @ 3,000 RPM
Max Operating Pressure	3,000 PSI / 200 Bar
Relief Valve Setting	Factory set 2,500 PSI — field adjustable to 3,000 PSI
Reservoir (Tank)	18 litres (usable)
Port Standard	9/16" UNO SAE6# (O-ring face seal)
Valve Configuration	P + T ports only — no valve fitted	1 × Cetop 3 D/A solenoid, closed centre, 12V DC
Solenoid Voltage	N/A	12V DC only
Mounting	Horizontal
Engine Weight (Recoil)	36kg	48.5kg
Engine Weight (Electric Start)	41kg	53.5kg
Emissions	EPA Tier 2 compliant
Remote Control	N/A	2 Button Pendant compatible (not included)

📄 Official Engine Documentation

› Yanmar L-Series Engine Specification Sheet — view or download the official Yanmar L-Series data sheet (PDF)

Tank upgrades available as cost-plus options: 21L, 22L, 30L, 38L. Additional sandwich valve spools available up to 3 spools total. Non-standard spool centres (Tandem, Open, Float, Single Acting) available on request. Contact us to discuss.

ℹ Port Standard — 9/16" UNO SAE6# (Read Before Ordering Hose)

All ports on this unit are 9/16" UNO (SAE6#) O-ring face seal standard. UNO ports use the same thread as JIC fittings but seal via an O-ring crushed into a face groove — not a 37° JIC flare seat. A JIC/UNO adaptor is required to connect standard JIC hose ends to these ports. For hose assemblies with BSPP ends, use a BSPP × JIC adaptor at the hose end plus a JIC/UNO adaptor at the port. See our JIC / UNO adaptor range for the fittings you need.

⚠ Solenoid Voltage — 12V DC Only

The solenoid valve on the Double Acting variant operates on 12V DC only. These units run on the engine's own starting battery. 24V solenoids are not available and not compatible. Do not attempt to run 12V solenoids on 24V systems.

⚠ Tank Installation — Warranty Condition

The oil reservoir must be properly supported and isolated against vibration and mechanical stress during installation. Improper mounting that allows the tank to flex, vibrate unsupported, or bear external load will void the tank warranty. Ensure the tank is correctly mounted and braced before operating the unit.

Freight — Australia-Wide Delivery

These units are heavy and bulky. Freight is not included in the listed price and is calculated based on your delivery location and carrier. For remote areas, or if you'd like a freight estimate before committing to an order, please call us on (07) 5563 1982 or contact us online and we'll provide a quote.

Not Sure Which Engine Size or Configuration Is Right?

Tell us what you're powering — cylinder bore size, stroke length, cycle speed, and duty cycle — and we'll confirm the right engine size and valve configuration for your application.
