Youli MB3 Monoblock Valve - Joystick Control, 45 L/min, 3/8" BSPP

One hand, two functions: a dual-axis joystick drives two MB3 spools at once via cable connectors - push/pull for one function, left/right for the other, and diagonal for both together. The natural setup for cranes, loaders and grabs.

Pick your setup from the dropdown - each is an assembled unit (valve + joystick(s) + cable connectors) with its own part number. All prices include GST.

Sizes & Part Numbers

What is in each kit: KIT-MB3-2S-JOY = MB3/2S3/18L/G4-3-4-M3 valve (2x double-acting cylinder spools) + YLMB45002 dual-axis joystick + 2x YLMB45003 cable connectors. KIT-MB3-4S-JOY2 = MB3/4S3/18L/G4-3-4-M3 valve (4x cylinder spools) + 2x YLMB45002 + 4x YLMB45003. Assembled and tested by us before dispatch. Motor or float spools on any lever - factory-coded, call us.

Specifications

• Flow: 45 L/min | Pressure: 250 bar nominal | Ports: 3/8" BSPP
• Adjustable inlet relief valve | Made in Taiwan (Youli)

Technicians Advice

Joystick cables need a smooth route - tight bends make the stick heavy and wear the cables early. Mount the joystick console within natural reach and leave service access to the connectors. Other spool counts (3-spool with one joystick + one lever, 6-spool with three sticks) are assembled to order - call us.

Official Datasheets

📄 Youli MB3 Factory Spec Sheet

Complete Your Setup

⚙ MB3 2-Spool (levers)⚙ MB3 4-6 Spool (levers)⭐ Power Beyond Plugs

Buy in bulk and save: 5+ units −5%, 10+ −10%, 25+ −12.5%, 50+ −15% — applied automatically in the cart.

Not sure? Call 1300 146 737 or email sales@mhfgc.com.au - we will spec it with you.
