Youli MB3/MB4 Monoblock Valve - 1 Spool Pneumatic (Air) Operated, 45-60 L/min

Air-over-hydraulic control: a single-spool Youli monoblock (double-acting cylinder spool) with the ON/OFF pneumatic actuator factory-fitted - operate the valve from a cab air switch or air pilot, no linkages. The classic truck tipper and remote-mount setup.

Pick your flow size from the dropdown - each is an assembled unit with its own part number. All prices include GST.

Sizes & Part Numbers

What is in each kit: KIT-MB3-1S-PN = MB3/1S3/18L/G4-3-4-M3 valve (cylinder/DA spool, 3/8" BSPP, 45 L/min) + YLMB44080 pneumatic actuator. KIT-MB4-1S-PN = MB4/1S3/18L/G4-M3 valve (cylinder/DA spool, 1/2" BSPP, 60 L/min) + YLMB44080. Assembled and tested by us before dispatch. Actuator seal kit available (YLMB44080-SK).

Specifications

• MB3: 45 L/min, 250 bar, 3/8" BSPP | MB4: 60 L/min, 315 bar, 1/2" BSPP
• ON/OFF pneumatic actuator (2-position air control) | Made in Taiwan (Youli)

Technicians Advice

This is ON/OFF air control - the spool goes to full stroke, no feathering. Run clean dry air and keep the signal line protected; a kinked airline is the usual "valve stopped working" culprit. For proportional or electric push-button control see the solenoid MB3 below.

Official Datasheets

📄 Youli MB3 Factory Spec Sheet📄 Youli MB4 Factory Spec Sheet

Complete Your Setup

⚙ MB3 Solenoid Operated (electric)⚙ MB4 1-6 Spool (manual)⭐ Power Beyond Plugs

Buy in bulk and save: 5+ units −5%, 10+ −10%, 25+ −12.5%, 50+ −15% — applied automatically in the cart.

Not sure? Call 1300 146 737 or email sales@mhfgc.com.au - we will spec it with you.
