Tractor PTO Speed Increase Gearbox Up To 70 Lt/min with Hydraulic Gear Pump Italian Quality

Hydraulic PTO 20 kW Speed Increase Gearbox Complete with Group 2 or Group 3 Gear Pump.

7100 series
Brand new P.T.O gearbox and pump assemblies are ideal for adding Additional Hydraulic power to tractors and landscape equipment not already equipped with hydraulic circuits.

Used to power all sorts of Hydraulic Attachments and Implements including, Auger, Post Hole Borers, Spreaders, Slashers, Front-end loaders, Mowers, Rotary sweepers etc.

The gearboxes are used mainly for connecting hydraulic pumps to the power take-offs of agricultural tractors. PTO output, standardised at either 540 or 1,000 rpm, is, in this way, increased to optimum operating speeds for the hydraulic pumps. At 540 Rpm, the output speed is 1620 RPM

This gearbox and pump offer either direct or remote mounting options to the tractor P.T.O to provide independent hydraulic service.

THERE IS ALSO THE OPTION OF A SHAFT 'QUICK RELEASE COUPLER

This step up gearbox has a ratio of 3:1 with a Group 3 Din Mount 1:8 tapered shaft Hydraulic gear pump.

With 540 input RPM the gearbox will produce 1620 rpm, giving a flow rate of litres per min;

Please see the examples below (other incremental pump sizes available,)

Please note; This gearbox is rated for a maximum of 20 kW hydraulic power.

If you oversize the pump, & run at a higher pressure than is stated in the chart below, internal stress will cause the gearbox to fail prematurely
