Hydraulic Gerolor Motor BMPH Series, Danfoss, DH, EATON H, M+S MP, PARKER TB, WHITE WD

Name: Gerolor Type high torque Low Speed Hydraulic Motor BMPH Series
Brand: M+S Europe
SKU: BMPH
Price: 495.0 AUD
Availability: InStock

Store/Motors Gear Geroler Orbital Radial

SKU BMPH

AU$495.00

🔥 EOFY SALE!

Motor Size / Displacement (CC's)

Please choose

Mount

Please choose

Shaft

Please choose

In stock

Quantity:

Save this product for later

Customer reviews

Reviews only from verified customers

No reviews yet. You can buy this product and be the first to leave a review.

Hydraulic Gerolor Motor BMPH Series, Danfoss, DH, EATON H, M+S MP, PARKER TB, WHITE WD

Store/Motors Gear Geroler Orbital Radial

Product Details

Brand: M+S Europe

Weight: 7.00 kg

HYDRAULIC BMPH Series Gerolor Motor, interchages with, Danfoss DH, EATON H, M+S MP, PARKER TB, WHITE WD

Available in sizes ; 30 cc to 400CC Per Revolution

These are high quality M+S Gerolor Motors made in Europe.
These hydraulic motors are suitable for many low-speed applications i.e. eliminating gears, shafts, chains, belts, pulleys and other speed reduction components.

Low weight with hight torque:
All motors are compact and light in weight in proportion to the torque and power delivered, they are all fully reversible.
These motors are useful where space is tight, high torque & low speed are required.

Part	Disp. (CC)	Max Speed (RPM)	Max Flow (LPM)	Pressure Drop (Bar)	Inlet Pressure (Bar)	Torque (Nm)	Weight (Kg)
H.O HP 25 C4UE	28.40	1,200	30	100	140	33	5.50
H.O HP 32 C4UE	34.50	1,250	40	125	140	52	5.50
H.O HP 40 C4UE	40.50	1,000	40	125	140	65	5.60
H.O HP 50 C4UE	49.50	1,212	45	125	140	81	5.70
H.O HP 60 C4UE	59.50	983	50	125	140	89	5.70
H.O HP 80 C4UE	79.20	758	60	125	140	129	5.80
H.O HP 100 C4UE	99.00	606	60	125	140	162	6.00
H.O HP 125 C4UE	123.80	485	60	125	140	202	6.10
H.O HP 160 C4UE	158.40	379	60	115	140	238	6.30
H.O HP 200 C4UE	198.00	303	60	105	140	271	6.50
H.O HP 250 C4UE	247.50	242	60	100	140	323	6.70
H.O HP 315 C4UE	316.80	189	60	90	140	372	7.00
H.O HP 400 C4UE	396.00	152	60	80	140	414	7.50

These motors are equivalent to these manufacturers:

Brevini / Sam BH
Danfoss DH,
Eaton Char Lynn, H Series ,
M+S, HP,
Parker TB,
Rosss/TRW MG,
White WD (145)

Manufactured to fine tolerances:
Hydraulics demands extremely fine tolerances & quality materials.
M+S, has been producing tight tolerance hydraulic motors for over 20 years.
We offer a 12-month warranty with the purchase of these motors.

Common UNO Ports:
These Gerolor motors come with A and B Ports in 7/8” UNO and a 7/16” UNO Drain port.

High load Needle bearings + 200 Bar shaft seals

We are a functioning hydraulic service center, so feel free to call with any questions or message us for prices on hydraulic adaptors and other items.

If you are unsure about identifying your pump, please clean & send a photo of the numbers and letters stamped in the body and nameplate of the pump. Optionally send a photo with the length, width, bolt hole and centre dimensions.

Please refer to the chart in the photos for dimensions, shafts ports etc.

Seal kits are available for just $68.

Postage is a $25 flat rate

Tax invoices are supplied with every purchase

Call us on 07 5563 1982 or email us by clicking here
Messages will be answered within normal business hours (ie: 8.00 AM - 4.00 PM Monday -Friday QLD Time)
