BSP Tapered Male x Female x Female Run Tee

A BSPT male with two BSPT female ports. Screws into a tapered port and gives two more female connections off the run.

Brand: Ayrtec – mild steel body with a plated finish, manufactured to the standards listed below.

Watch: How to Identify Hydraulic Hose Fittings and Hydraulic Adaptors JIC and BSP

Thread Standards

• BSP Tapered Male – BSPT to ISO 7 / BS 21. It seals on the tapered thread itself, so it needs PTFE tape or a liquid thread sealant.
• BSP Tapered Female – BSPT to ISO 7 / BS 21. It seals on the thread interference and must be taped or sealed.

How to Choose

• On a run tee the odd port sits in the middle of the run and the two matching ports are the ends. It is the opposite layout to a branch tee, so check which one the job needs before you order.
• Every joint on this part seals on the thread, so the male and both mating males need sealant.
• BSPT is 55° and NPT is 60°. Identify every mating part before you fit.

Technicians Advice

The females split if a male is over-tightened into them. Hand tight plus two or three turns everywhere, and let the sealant close each joint rather than the spanner.

Where You’ll Find It

• BSP Tapered Male – Older Australian and British pipework, gauge ports, tank and return lines, and cast pump and gearbox housings.
• BSP Tapered Female – Female side of local pipework, adaptor blocks and gauge manifolds.

Cross-Reference

• BSP Tapered Male – BSPT to ISO 7 / BS 21, written R for male. Sometimes labelled PT or BSP taper.
• BSP Tapered Female – BSPT to ISO 7 / BS 21, written Rc for female.

Parker, Gates, Aeroquip and Ryco all manufacture to these same standards under their own part numbering, so a fitting built to the standard above will mate with theirs.

Cross-references are given at series level as a guide to the standard, not as a part-for-part substitution. Always confirm the thread form, size and seal type against the port before ordering.

📐Dimensions & thread sizes – every size in this range

← Swipe the table sideways to see every measurement →

Part code	A	B	S1	C	Material	Finish
BTM-BTF-BTF-080808	1/2" BSPT	1/2" BSPT	27mm	1/2" BSPT	Mild steel	Plated finish
BTM-BTF-BTF-121212	3/4" BSPT	3/4" BSPT	33mm	3/4" BSPT	Mild steel	Plated finish
BTM-BTF-BTF-020202	1/8" BSPT	1/8" BSPT	16mm	1/8" BSPT	Mild steel	Plated finish
BTM-BTF-BTF-040404	1/4" BSPT	1/4" BSPT	19mm	1/4" BSPT	Mild steel	Plated finish
BTM-BTF-BTF-060606	3/8" BSPT	3/8" BSPT	24mm	3/8" BSPT	Mild steel	Plated finish
BTM-BTF-BTF-161616	1" BSPT	1" BSPT	41mm	1" BSPT	Mild steel	Plated finish

Key: S1 hex across flats 2, C across corners. Measurements in millimetres unless shown otherwise. Thread columns show what each end mates with. Dimensions are nominal – check critical clearances against the part.
