BSP Tapered Male Blanking Plug

A BSP tapered male plug for blanking off an unused BSPT port. The everyday blanking plug on Australian and British-built gear.

Brand: Ayrtec – mild steel body with a plated finish, manufactured to the standards listed below.

Watch: Why You Need JIC Plugs Caps & O Ring Kit When Doing Hydraulic Repairs

Thread Standards

• BSP Tapered Male – BSPT to ISO 7 / BS 21. It seals on the tapered thread itself, so it needs PTFE tape or a liquid thread sealant.

How to Choose

• A plug is male and blocks a female port. A cap is female and covers a male end. Work out which one the open connection is before you order.
• The tapered thread seals on itself and needs sealant. Anaerobic sealant or PTFE tape wound the way the thread turns.
• BSPT is 55°. A 60° NPT plug will start and then tear the port thread out.

Technicians Advice

Hand tight plus two or three turns and stop. A tapered plug wedges as it goes, and winding one hard into a cast valve body is one of the easier ways to crack a housing for no good reason.

Where You’ll Find It

• BSP Tapered Male – Older Australian and British pipework, gauge ports, tank and return lines, and cast pump and gearbox housings.

Cross-Reference

• BSP Tapered Male – BSPT to ISO 7 / BS 21, written R for male. Sometimes labelled PT or BSP taper.

Parker, Gates, Aeroquip and Ryco all manufacture to these same standards under their own part numbering, so a fitting built to the standard above will mate with theirs.

Cross-references are given at series level as a guide to the standard, not as a part-for-part substitution. Always confirm the thread form, size and seal type against the port before ordering.

📐Dimensions & thread sizes – every size in this range

← Swipe the table sideways to see every measurement →

Part code	L	H1	Material	Finish
BTM-02	16mm	12mm	Mild steel	Plated finish
BTM-04	20mm	14mm	Mild steel	Plated finish
BTM-06	21mm	17mm	Mild steel	Plated finish
BTM-08	27mm	22mm	Mild steel	Plated finish
BTM-10	28mm	24mm	Mild steel	Plated finish
BTM-12	29mm	27mm	Mild steel	Plated finish
BTM-16	37mm	36mm	Mild steel	Plated finish
BTM-20	39mm	46mm	Mild steel	Plated finish
BTM-24	42mm	50mm	Mild steel	Plated finish
BTM-32	47mm	65mm	Mild steel	Plated finish

Key: L overall length, H1 centre to face 2. Measurements in millimetres unless shown otherwise. Thread columns show what each end mates with. Dimensions are nominal – check critical clearances against the part.

Downloads

📄 Thread Identification Chart (PDF)
