BSP Parallel Male x JIC 37° Male x JIC 37° Male Run Tee

A BSP parallel male in the middle of the run with a JIC male at each end. Feeds a BSPP port from a JIC line running past it.

Brand: Ayrtec – mild steel body with a plated finish, manufactured to the standards listed below.

Watch: How to Identify Hydraulic Hose Fittings and Hydraulic Adaptors JIC and BSP

Thread Standards

• JIC 37° Male – SAE J514 37° flare. It seals metal-to-metal on the 37° cone, so it takes no tape at all.
• BSP Parallel Male – BSPP to ISO 228. It seals on a bonded washer against the port face or on a 60° cone, never on the thread itself.

How to Choose

• On a run tee the odd port sits in the middle of the run and the two matching ports are the ends. It is the opposite layout to a branch tee, so check which one the job needs before you order.
• The BSPP port needs a bonded washer or a cone seat. The two JIC ends seal dry on their cones.
• Keep sealant off both JIC cones.

Technicians Advice

Get the BSPP leg seated in its port before you bring the hoses on. Once both JIC ends are connected you have nothing clean to hold while you correct the middle.

Where You’ll Find It

• JIC 37° Male – Hose ends and ports on imported US and Asian machinery – Caterpillar, John Deere, Case IH, New Holland, Bobcat, Kubota, Takeuchi.
• BSP Parallel Male – Valve and manifold ports on Australian, British and Asian-built equipment, and most locally made hose ends. The default port thread on Australian truck and agricultural hydraulics.

Cross-Reference

• JIC 37° Male – SAE J514 / ISO 8434-2 37° flare. Parker call this series Triple-Lok. The industrial cousin of the AN 37° flare used in aviation and motorsport.
• BSP Parallel Male – BSPP to ISO 228 / BS 2779, written G. Also called BSP parallel or gas thread.

Parker, Gates, Aeroquip and Ryco all manufacture to these same standards under their own part numbering, so a fitting built to the standard above will mate with theirs.

Cross-references are given at series level as a guide to the standard, not as a part-for-part substitution. Always confirm the thread form, size and seal type against the port before ordering.

📐Dimensions & thread sizes – every size in this range

← Swipe the table sideways to see every measurement →

Part code	A	B	H	S1	C	Material	Finish
BPM-JIM-JIM-020707	7/16" JIC	1/8" BSPP	14mm	11mm	7/16" JIC	Mild steel	Plated finish
BPM-JIM-JIM-020808	1/2" JIC	1/8" BSPP	14mm	14mm	1/2" JIC	Mild steel	Plated finish
BPM-JIM-JIM-040707	7/16" JIC	1/4" BSPP	19mm	14mm	7/16" JIC	Mild steel	Plated finish
BPM-JIM-JIM-040909	9/16" JIC	1/4" BSPP	19mm	14mm	9/16" JIC	Mild steel	Plated finish
BPM-JIM-JIM-060909	9/16" JIC	3/8" BSPP	22mm	16mm	9/16" JIC	Mild steel	Plated finish
BPM-JIM-JIM-061212	3/4" JIC	3/8" BSPP	22mm	19mm	3/4" JIC	Mild steel	Plated finish
BPM-JIM-JIM-081212	3/4" JIC	1/2" BSPP	27mm	22mm	3/4" JIC	Mild steel	Plated finish
BPM-JIM-JIM-081414	7/8" JIC	1/2" BSPP	27mm	22mm	7/8" JIC	Mild steel	Plated finish
BPM-JIM-JIM-081717	1.1/16" JIC	1/2" BSPP	27mm	27mm	1.1/16" JIC	Mild steel	Plated finish
BPM-JIM-JIM-121717	1.1/16" JIC	3/4" BSPP	32mm	27mm	1.1/16" JIC	Mild steel	Plated finish
BPM-JIM-JIM-162121	1.5/16" JIC	1" BSPP	41mm	33mm	1.5/16" JIC	Mild steel	Plated finish
BPM-JIM-JIM-202626	1.5/8" JIC	1.1/4" BSPP	50mm	41mm	1.5/8" JIC	Mild steel	Plated finish

Key: H centre to face, S1 hex across flats 2, C across corners. Measurements in millimetres unless shown otherwise. Thread columns show what each end mates with. Dimensions are nominal – check critical clearances against the part.
